China Class 900 Reduced Port Forged DBB Trunnion-Mounted Cryogenic Ball Valve Manufacturers, Factories

China Class 900 Reduced Port Forged DBB Trunnion-Mounted Cryogenic Ball Valve Manufacturers, Factories

Reduced Port Design: Minimizes turbulence and pressure drop, optimizing flow control in critical cryogenic systems.

DBB Technology: Double Block and Bleed (DBB) design guarantees leak prevention and enhanced safety in extreme environments.

Forged Trunnion-Mounted Construction: Offers superior stability and durability, ensuring reliable performance under high-pressure and low-temperature conditions.

Cryogenic Performance: Reliable sealing and performance in temperatures as low as -196°C, ideal for LNG, Liquid Nitrogen (LN₂), and Liquid Oxygen (LOX).

Rigorous Testing & Materials: Available in A350 LF2, Inconel 625, and Hastelloy, with each valve rigorously tested in-house for consistent quality and long service life.

Send Inquiry

Product Description

⭐ Key Features

⚙️
Reduced Port Design
Minimizes turbulence and pressure drop, making it ideal for flow-sensitive applications.
🛡️
DBB Technology
Double Block and Bleed (DBB) design ensures superior safety and leak prevention.
🏗️
Trunnion-Mounted Forged Construction
Enhances stability and durability in high-pressure and low-temperature environments.
❄️
Cryogenic Performance
Guarantees reliable sealing and performance at temperatures as low as -196°C.
💎
Materials
Available in A350 LF2, Inconel 625, Hastelloy C, and other materials to meet diverse industrial needs.
🧪
Rigorous Testing
Each valve undergoes comprehensive in-house cryogenic testing to ensure consistent, reliable performance.

📝 Product Details

The Class 900 Reduced Port Forged DBB Trunnion-Mounted Cryogenic Ball Valve is built for reliable shut-off in extreme low-temperature applications. Its reduced port design minimizes turbulence and pressure drop, making it ideal for flow-sensitive systems.

With a forged trunnion-mounted construction and Double Block and Bleed (DBB) technology, this valve ensures safety, leak prevention, and easy maintenance. It is perfect for cryogenic fluids like LNG, Liquid Nitrogen (LN₂), and Liquid Oxygen (LOX), delivering dependable performance in harsh conditions.

Available in materials such as A350 LF2, Inconel 625, and Hastelloy, it meets global standards (ASME B16.34, GB/T14925). Each valve is rigorously tested in-house for consistent quality and long service life in low-temperature environments.

Class 900 Reduced Port Forged DBB Trunnion

📊 Technical Specifications

Parts List Technical Specifications

Dimensions: Class 900 - Reduced Port

Size Bore Side Entry Top Entry
Face to Face D in/mm D1 in/mm Weight Face to Face D2 in/mm Weight
NPS/DN B1 in/mm B2 in/mm RF in/mm RTJ in/mm BWE in/mm Model GG lb/kg Model GW lb/kg RF in/mm RTJ in/mm BWE in/mm Model FT lb/kg
2"×1 1/2" 1.93 1.5 14.5 14.63 14.5 8.5 8.5 108 108 14.5 14.63 14.5 8.5 110
50×40 49 38 368 371 368 216 216 49 49 368 371 368 216 50
3"X2" 2.94 1.94 15 15.13 15 9.5 9.5 150 150 15 15.13 15 9.5 159
80×50 74 49 381 384 381 241 241 68 68 381 384 381 241 72
4"X3" 3.94 2.94 18 18.13 18 11.5 11.5 254 254 18 18.13 18 11.5 320
100×80 100 74 457 460 457 291 291 115 115 457 460 457 291 145
6"×4" 5.94 3.94 24 24.13 24 15 15 481 481 24 24.13 24 15 595
150×100 150 100 610 613 610 381 381 218 218 610 613 610 381 270
8"×6" 7.94 5.94 29 29.13 29 18.5 18.5 948 948 29 29.13 29 18.5 1257

Weight and dimensions for larger valve sizes up to 36" available on request.

Technical Information

❓ Frequently Asked Questions

What is the lowest temperature this valve can handle?
This cryogenic ball valve is specifically designed for extreme low-temperature performance, guaranteed to operate reliably at temperatures as low as -196°C.
Why choose a Trunnion-Mounted design for cryogenic applications?
The trunnion-mounted construction provides enhanced stability and mechanical support for the ball, which reduces operating torque and ensures consistent sealing under high-pressure cryogenic conditions.
What are the benefits of the Double Block and Bleed (DBB) technology?
DBB technology allows the valve to seal from both the upstream and downstream sides simultaneously. This enables the cavity between the seats to be vented or drained, providing superior safety and leak prevention.
Which standards does this valve comply with?
Our cryogenic valves meet major global standards including ASME B16.34 and GB/T14925, ensuring they fulfill the rigorous requirements of international industrial applications.
What materials are available for custom orders?
We offer a wide range of high-performance materials including A350 LF2, Inconel 625, and Hastelloy C to suit specific chemical and temperature requirements of your project.
Is every valve tested before shipment?
Yes, each individual valve undergoes rigorous in-house cryogenic testing and pressure trials to ensure it meets our strict quality and safety standards before reaching the customer.
