Double-Block-and-Bleed (DBB), Anti-Static, Fire-Safe, Anti-Blowout Stem, and Low Fugitive Emission Packing ensure maximum safety and leak prevention in critical applications.
Engineered to perform in extreme cold conditions down to -196°C, with PCTFE Cryogenic Seats and Lip-Seal Compensation for a tight, leak-free seal even under low temperatures.
Forged trunnion-mounted design ensures durability and reliable operation at temperatures as low as -46°C, with resistance to both low temperatures and high-pressure conditions.
Every valve undergoes rigorous in-house cryogenic testing to guarantee reliable, leak-free operation and performance in the most demanding low-temperature environments.
Ideal for cryogenic fluids such as LNG, Liquid Nitrogen (LN₂), Liquid Oxygen (LOX), Liquid Hydrogen (LH₂), and other high-flow fluids, as well as industrial pipelines.
Available in a variety of sizes (2" to 36", DN50 to DN900) and materials such as A350 LF2, F316(L), Inconel 625, Hastelloy C, etc.
The Class 300 Cryogenic Ball Valve is engineered for reliable performance in extreme low-temperature conditions, down to -196°C. Featuring a trunnion-mounted ball and durable materials like F316(L) and Inconel 625, it ensures leak-free operation under both low temperatures and high pressures. Advanced sealing materials such as PEEK and PCTFE provide long-lasting, dependable sealing.
Ideal for cryogenic fluids like LNG, LN₂, LOX, and LH₂, it offers versatile actuation options including manual, electric, pneumatic, and hydraulic. Built to meet global standards (GB/T14925, ASME B16.34), each valve undergoes rigorous in-house testing to ensure consistent, high-quality performance.
Dimensions: Class 300 - Full Port
| Size NPS/DN | Bore (in/mm) | Model / Face to Face (Side Entry) | Weight (lb/kg) | |||||
|---|---|---|---|---|---|---|---|---|
| B1 | B2 | RF | RTJ | BWE (FF) | BWE (FW) | Model FF | Model FW | |
| 2" / 50 | 1.94 / 49 | 1.94 / 49 | 8.5 / 216 | 9.13 / 232 | 8.5 / 216 | 11 / 279 | 60 / 27 | 60 / 27 |
| 3" / 80 | 2.94 / 74 | 2.94 / 74 | 11.13 / 283 | 11.75 / 298 | 11.13 / 283 | 12.5 / 318 | 132 / 60 | 132 / 60 |
| 4" / 100 | 3.94 / 100 | 3.94 / 100 | 12 / 305 | 12.63 / 321 | 12 / 305 | 14 / 356 | 179 / 81 | 179 / 81 |
| 6" / 150 | 5.94 / 150 | 5.94 / 150 | 15.88 / 403 | 16.5 / 419 | 18 / 457 | 18 / 457 | 408 / 185 | 397 / 180 |
Dimensions: Class 300 - Reduced Port
| Size NPS/DN | Bore B1 | Bore B2 | RF (in/mm) | RTJ (in/mm) | BWE FF | BWE FW | Weight FF | Weight FW |
|---|---|---|---|---|---|---|---|---|
| 2"×1 1/2" / 50×40 | 1.94 / 49 | 1.5 / 38 | 8.5 / 216 | 9.13 / 232 | 8.5 / 216 | 11 / 279 | 57 / 26 | 57 / 26 |
| 3"×2" / 80×50 | 2.94 / 74 | 1.94 / 49 | 11.13 / 283 | 11.75 / 298 | 11.13 / 283 | 12.5 / 318 | 88 / 40 | 88 / 40 |
Weight and dimensions for larger valve sizes up to 36" available on request.
