China High-Integrity DBB Ball Valve Factory in China | Severe Service Metal-Seated Suppliers for Critical Isolation Manufacturer, Suppliers

âˆš Severe Service DBB Ball Valves by a Leading Metal-Seated Specialist in China
Designed and manufactured by one of the most reliable suppliers in the industry, our ball valves incorporate advanced hard sealing DBB technology.

âˆš True DBB Structure with Optimized Sealing Loads
This design guarantees dependable double isolation and safe cavity pressure relief, making it ideal for ultra-high pressure environments.

âˆš Heavy-Duty Gear-Operated Design for Superior Performance
Engineered for large-bore, high-pressure applications, ensuring smooth and stable operation even in the most demanding conditions.

âˆš Fire-Safe & Anti-Static Features Integrated
Built-in safety mechanisms cater to hazardous and critical services, enhancing reliability in various applications.

âˆš Engineered for Critical Pipelines
Our products have a proven track record in Oil & Gas, Petrochemical, and other severe process environments, manufactured in our state-of-the-art factory.

Send Inquiry

Product Description

Key Features

Heavy-Duty Forged Body with Thick Flanged

Forged valve body combined with thick flanges and multi-bolt connections, providing superior pressure containment, load distribution, and structural rigidity for severe service.

Trunnion-Mounted Ball Design

Fixed ball supported by upper and lower trunnions to minimize ball deflection, ensuring stable operation and reliable sealing under ultra-high pressure DBB service.

True DBB Configuration

Dual sealing seats provide complete upstream and downstream isolation, with controlled cavity pressure relief to enhance pipeline safety.

Proven Metal-Seated Sealing System

Metal-to-metal sealing technology engineered for high temperature, high pressure, and abrasive or corrosive media, delivering long-term sealing integrity.

Heavy-Duty Gear-Operated Mechanism

Worm gear operation ensures controlled torque output and smooth, stable operation for large-bore, high-pressure applications.

Fire-Safe & Anti-Static Design

Integrated safety features designed in accordance with fire-safe and anti-static requirements, ensuring operational integrity in hazardous conditions.

Frequently Asked Questions

What is the advantage of a trunnion-mounted ball valve over a floating ball valve in high-pressure applications?

In a trunnion-mounted ball valve, the ball is mechanically anchored by upper and lower trunnions, which absorbs pipeline pressure loads and prevents ball deflection. This makes it significantly more suitable for high-pressure and large-bore applications compared to floating ball valves.

What does DBB (Double Block and Bleed) mean, and why is it important?

DBB refers to a valve configuration that provides two independent sealing surfaces (upstream and downstream) and a bleed/vent connection to relieve the trapped cavity pressure between them. This allows operators to safely isolate sections of a pipeline for maintenance.

In what conditions is a metal-seated sealing system preferred over a soft-seated design?

Metal-seated sealing systems are preferred in environments involving high temperatures, high pressures, or media that are abrasive, corrosive, or contain particulates where elastomeric designs might fail.

Why is a heavy-duty forged body important for severe service ball valves?

A forged valve body offers superior strength and enhanced resistance to pressure compared to cast bodies. When combined with thick flanges, it ensures optimal pressure containment and safety under cyclical loading.

What is the purpose of the fire-safe and anti-static design in ball valves?

Fire-safe design ensures the valve maintains a seal even if non-metallic components are destroyed by fire. Anti-static features prevent the buildup of static charge, reducing ignition risks in flammable environments.

When should gear operation be selected for a ball valve?

Gear operation is recommended for large-bore valves (typically 6" and above) and high-pressure applications where operating torque exceeds what can be handled manually with a lever.
