China High-Pressure Metal Seated DBB Trunnion Mounted Electric Actuated Ball Valve from China Suppliers and Factory Suppliers, Factory

âˆš Our trunnion mounted structure is designed to ensure low operating torque and stable sealing, making it ideal for high-pressure applications.

âˆš Featuring a metal seated design, this valve guarantees a long service life, even in high temperature, abrasive, and frequent cycling environments.

âˆš The heavy-duty split body coupled with thick flanges provides exceptional mechanical strength and reliable pressure containment.

âˆš With electric actuation, our valves enable reliable remote operation and seamless integration with automated control systems, enhancing operational efficiency.

âˆš As a leading factory and supplier in China, SLVCN is committed to the research, development, design, and manufacturing of valves for severe service, boasting proven performance in over 1,000 international projects.

Send Inquiry

Product Description

Key Features

Trunnion Mounted Ball Design

Upper and lower bearings support the ball, minimizing operating torque and ensuring stable performance under high pressure and large diameter conditions.

Heavy-Duty Split Body Construction

Multi-bolt split body with reinforced flanges offers high structural strength, excellent pressure resistance, and convenient maintenance for severe service.

Metal Seated Sealing Structure

Metal-to-metal sealing provides reliable shut-off performance in high temperature, high pressure, abrasive, and particle-containing media.

Electric Actuation & Safety Design

Top-mounted electric actuator enables remote on/off control and seamless integration with automated control systems. Anti-static and fire-safe features enhance safety and sealing reliability in hazardous environments.

Frequently Asked Questions

What is a trunnion mounted ball valve and how does it differ from a floating ball valve?

A trunnion mounted ball valve features upper and lower trunnion bearings that fix the ball in place, absorbing pipeline pressure and reducing operating torque. Unlike floating ball valves where the ball shifts under pressure to seal, the trunnion design is ideal for high-pressure, large-diameter applications requiring stable and consistent performance.

What are the advantages of a heavy-duty split body construction?

The split body design uses multiple bolts and reinforced flanges to deliver superior structural strength and pressure resistance. It also simplifies maintenance — the valve internals can be accessed and serviced without removing the entire body from the pipeline, reducing downtime in severe service environments.

In which applications is a metal seated sealing structure recommended?

Metal seated sealing structures are recommended for applications involving high temperatures, high pressures, abrasive media, or fluids containing solid particles — such as steam lines, slurry systems, petrochemical processing, and power generation. Metal-to-metal contact ensures reliable shut-off where soft seats would degrade or fail.

How does the electric actuator integrate with automated control systems?

The top-mounted electric actuator supports standard control signal interfaces (e.g., 4–20mA, on/off signals), allowing seamless integration with DCS, PLC, or SCADA systems. This enables remote operation, real-time valve position feedback, and automated open/close control without manual intervention.

What do anti-static and fire-safe features mean for this valve?

Anti-static design includes grounding paths between the ball, stem, and body to dissipate static electricity buildup — critical for flammable or explosive media. Fire-safe design ensures the valve maintains a reliable seal even if the primary soft seat is damaged by fire, preventing uncontrolled leakage and meeting international standards such as API 607 or ISO 10497.

What maintenance is required for a trunnion mounted ball valve with metal seating?

Routine maintenance includes periodic inspection of the seat and ball surfaces for wear or erosion, checking actuator function and electrical connections, verifying stem packing integrity to prevent leakage, and lubricating bearing surfaces as specified. The split body construction facilitates easy internal access, reducing maintenance complexity and service time.
